High-efficiency 3kW hybrid solar inverter with 24V input, MPPT 100A controller, and 40–500Vdc PV input range. Supports both solar and AC charging (up to 60A) for off-grid or backup power systems. Optional parallel function enables flexible expansion for residential or commercial energy applications.
Power: 3000W
Voltage: 24V
PV Open-Circuit Voltage: PV 40–500Vdc
Optimal Vmp Operating Range: 300–400Vdc
Maximum PV Input Power: 3000W
Maximum Solar Charging Current: MPPT 100A
Maximum AC Charging Current: 60A
Parallel Operation Support: Optional
